Eaton C25FNF360T Non-Reversing Definite Purpose Contactor 110 to 120 VAC Coil 60 A Inductive 75 A Resistive Frame F

Product Description

The Eaton C25FNF360T is a definite purpose contactor designed for use in HVAC applications. This contactor operates on a coil voltage of 110 to 120 volts AC at fifty or sixty hertz.

• Power rating: 10 HP at 230 volts AC for single-phase, 20 HP for three-phase.
• Current rating: 60 amps inductive and 75 amps resistive.
• Three poles, with one normally open (NO) and one normally closed (NC) auxiliary contact.

Product Highlights

This product is ideal for controlling motors and other HVAC devices. It is highly reliable and rated for a high number of operations.

Product Information

Standard Information

• Manufacturer: Eaton
• MPN: C25FNF360T

Technical Specifications

• Coil Voltage: 110 to 120 Volt AC, 50/60 Hertz
• Current Rating: 60 Amp
• Inductive Ampere: 60 Amp
• Resistive Ampere: 75 Amp
• Number of Poles: 3
• Auxiliary Contact: 1NO, 1NC
• Enclosure Type: Open
• Frame Size: Frame F
• Overall Dimensions: 2.63 inches width x 3.97 inches depth x 3.75 inches height
• Approval: UL (Canada and US), CSA, CE
• Locked Rotor Current Rating: 360 Amp at 230 Volt AC
• Construction Standard: EN 60947-4-1
