Eaton C25FNF350B Definite Purpose Contactor, 3-Pole, 240 VAC, 50 Amp

Product Description

The Eaton C25FNF350B is a definite purpose contactor designed for reliable and efficient performance. This 3-pole, non-reversing contactor operates on a coil voltage of 208 to 240 VAC at 50/60 Hz. It features a current rating of 50 amperes for inductive loads and 65 amperes for resistive loads. The open enclosure design allows for easy installation and maintenance.

• Voltage: 208 to 240 VAC, 50/60 Hz
• Current Rating: 50 A Inductive, 65 A Resistive
• Number of Poles: 3

Product Highlights

This Eaton contactor is built to handle tough HVAC applications, making it suitable for heating, ventilation, and refrigeration systems.

Product Information

Standard Information

• Manufacturer: Eaton
• MPN: C25FNF350B
• UPC: 782113476087

Technical Specifications

• Enclosure Type: Open
• Construction Standard: EN 60947-4-1
• Approval: UL, CSA
• Dimensions: 2.63 inches Width x 3.97 inches Depth x 3.75 inches Height
• Frame Size: F
• Connection Type: Quick Connect
• Terminal Type: Box Lug
• Current Rating: 50 A Inductive / 65 A Resistive
