Eaton C25FNF275A Definite Purpose Contactor 75A

Product Description

The Eaton C25FNF275A definite purpose contactor is rated for 75A and operates at 110-120 Vac, 50/60 Hz. It features an open design with a metal mounting plate and box lugs, along with quick connect terminals. This non-reversing contactor is suitable for various applications.

• Encased design is impervious to dust and environmental elements.
• Available in single, two, three, and four-pole configurations.
• UL LZGH2/8-certified for use with A2L refrigerants.

Product Highlights

The Eaton C25FNF275A is a reliable definite purpose contactor with an open enclosure and metal mounting plate.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: C25FNF275A

Technical Specifications

• SKU: C25FNF275A
• Product Name: Eaton definite purpose contactor
• Catalog Number: C25FNF275A
• UPC: 782114117439
• Product Length/Depth: 3.97 in
• Product Height: 3.75 in
• Product Width: 2.63 in
• Compliances: RoHS Compliant
• Certifications: CSA Certified UL Recognized
• Catalog Notes: Resitive Load rating per pole
• Product Type: Definite purpose contactor
• Amperage Rating: 75A
• Number of poles: Two-pole
• Type: Non-reversing
• Coil Voltage: 110-120 Vac, 50/60 Hz
• Enclosure: Open with metal mounting plate
• Frame size: 15-50 A, two-pole and three-pole
• Inductive full load: 75 A
• Model: Contactor
• Resistive load: 90 A
• Terminals: Box lugs (posidrive setscrew) and quick connect terminals (side-by-side)
• Connection: Quick
• Starter Coil Voltage: 110 VAC
• Starter Frequency: 50 Hz
• Component: NEMA Contactor
• Sub Component: Definite Purpose Contactor
• Starter Poles: Two Pole
• Starter Reversing Capability: Non-Reversing
• Starter Amperage: 75 Amp
• Manufacturer: Eaton
• Starter Class: C25
• Starter Enclosure Type: Open W/ Metal Mounting Plate
• Material: Steel
• Contactor Type: Non-Reversing Definite Purpose Contactor
• Frame Size: F
• Amps - inductive: 75A
• Amps - resistive: 90A
• Poles: 2P
