Eaton C25FNF260C Definite Purpose Contactor 60A

Product Description

The Eaton C25FNF260C definite purpose contactor is rated for 60A and 440-480 Vac at 50/60 Hz. This two-pole, non-reversing contactor features an open enclosure with a metal mounting plate. It includes box lugs (posidrive setscrew) and quick connect terminals (side-by-side). Suitable for various applications requiring reliable switching.

• Open enclosure with metal mounting plate
• Box lugs (posidrive setscrew) and quick connect terminals
• UL Recognized and CSA Certified

Product Highlights

The Eaton C25FNF260C contactor offers a robust solution for definite purpose applications, ensuring reliable performance and easy installation.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: C25FNF260C

Technical Specifications

• SKU: C25FNF260C
• Product Name: Eaton definite purpose contactor
• Catalog Number: C25FNF260C
• UPC: 782113499673
• Product Length/Depth: 3.97 in
• Product Height: 3.75 in
• Product Width: 2.63 in
• Compliances: RoHS Compliant
• Certifications: UL Recognized CSA Certified
• Catalog Notes: Resitive Load rating per pole
• Product Type: Definite purpose contactor
• Amperage Rating: 60A
• Number of Poles: Two-pole
• Type: Non-reversing
• Coil: 440-480 Vac, 50/60 Hz
• Enclosure: Open with metal mounting plate
• Frame size: 15-50 A, two-pole and three-pole
• Inductive full load: 60 A
• Model: Contactor
• Resistive load: 75 A
• Terminals: Box lugs (posidrive setscrew) and quick connect terminals (side-by-side)
• Connection: Quick
• Mounting Type: Panel Mount
• Current Rating: 60 A
• Starter Frequency: 50 Hz
• Starter Coil Voltage: 440 VAC
• Component: NEMA Contactor
• Sub Component: Definite Purpose Contactor
• Starter Reversing Capability: Non-Reversing
• Starter Poles: Two Pole
• Starter Amperage: 60 Amp
• Manufacturer: Eaton
• Starter Class: C25
• Starter Enclosure Type: Open W/ Metal Mounting Plate
