Eaton C25DNF350B definite purpose contactor 208 to 240 Vac 50 A 3 Poles

Product Description

The Eaton C25DNF350B is a definite purpose contactor suitable for various HVAC applications. This product operates at a voltage of 208 to 240 Vac and is designed for 50 A maximum load current with three poles. The contactor features quick-connect terminals for efficient installation and is equipped with a durable open enclosure. It is suitable for surface mounting and comes with a metal mounting plate.

• Voltage: 208 to 240 Vac
• Maximum Load Current: 50 A
• Number of Poles: 3

Product Highlights

Designed specifically for electrical assemblies, panels, and OEMs, the Eaton C25DNF350B contactor is ideal for HVAC systems. Its quick-connect terminals and non-reversing function simplify installation and maintenance.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Cutler-Hammer / Eaton

Technical Specifications

• Catalog Number: C25DNF350B
• Coil Voltage: 208 to 240 Vac
• Connection Type: Quick-Connect (Side by Side)
• Contact Type: Double Break
• Enclosure Type: Open with metal mounting plate
• Frequency Rating: 50/60 Hz
• Operating Temperature: 150 deg F Ambient
• Terminal Type: Box Lug (Posidrive Setscrew)
• Type: Non-Reversing
• Dimensions: 3.35 in L x 2.4 in W x 3 in H
• Maximum Load Current: 50 A
• Number of Poles: 3
• UPC: 782116311880
• GTIN: 00782116311880
• Standards/Approvals: UL Listed, CSA Certified, CE Marked, RoHS Compliant
