Product Description
The EATON C25DNF240A is a robust, non-reversing definite purpose AC contactor designed for optimized performance in the HVAC industry. Integral to controlling electric motors and other high-power loads, this contactor operates reliably within a voltage range of 110 to 120 VAC and is capable of handling up to 40 A inductive and 50 A resistive loads.
- Rated for 40 A inductive and 50 A resistive loads.
- 2-pole configuration with double-break contact type.
- Quick-connect side-by-side connections and box lug terminals.
Product Highlights
This contactor features a robust open enclosure and a built-in metal mounting plate for easy installation. Its compact dimensions (3.35 in L x 2.4 in W x 3.75 in H) make it suitable for confined spaces, enhancing its versatility across various applications.
Product Information
Standard Information
-
Operating Temperature: 150 degrees Fahrenheit ambient.
-
Connection Type: Quick-Connect (Side by Side).
Technical Specifications
-
Coil Voltage: 110 to 120 VAC.
-
Frequency Rating: 50/60 Hz.
-
Dimensions: 3.35 in Length x 2.4 in Width x 3.75 in Height.
-
Contact Type: Double Break.
-
Enclosure Type: Open with metal mounting plate.
-
Terminal Type: Box Lug (Posidrive Setscrew).
-
Number of Poles: 2.
-
Maximum Load Current: 40 A Inductive, 50 A Resistive.
