Product Description
The Eaton C25DND340T Definite Purpose Contactor is a high-performance 40-amp, 3-pole contactor for industrial control applications. With a 24V AC coil, it is designed for electrical assemblies, panels, and EOEMs needing reliable operation.
- 40A current capacity
- 3-pole configuration
- 24V AC coil voltage
Product Highlights
Ideal for HVAC and refrigeration, motor control, and load switching applications.
Product Information
Standard Information
-
Brand: Eaton
-
Manufacturer: Eaton
Technical Specifications
-
Amperage: 40 Amp
-
Coil Voltage: 24 VAC at 50/60 Hz
-
Connection Type: Quick
-
Dimensions: 3.35 in L x 2.4 in W x 3.75 in H
-
Enclosure: Open with metal mounting plate
-
Frame: 15-50 A
-
Height: 3.75 inches
-
Length: 3.35 inches
-
Width: 2.4 inches
-
Mounting Type: Surface
-
Number of Poles: 3 Pole
-
Operating Temperature: 150 degrees Fahrenheit
-
Operating Cycles: 300000 Cycles
-
Standards/Approvals: RoHS Compliant, UL Recognized, CSA Certified
-
Terminal Type: Screw/Pressure Plate
-
Weight: 1.19 lbs
