Eaton C25DND340A Definite Purpose Contactor 110-120 VAC 40A 3-Pole Non-Reversing

Product Description

Eaton's C25DND340A Definite Purpose Contactor is designed to efficiently handle high-power electrical loads, specifically tailored for HVAC applications, panels, and OEMs. This robust non-reversing, 3-pole contactor operates on a 110-120 VAC coil and is capable of managing up to 40 amps, making it ideal for industrial use.

• Quick-connect and screw/pressure plate terminals for easy installation.
• Open enclosure with a metal mounting plate.
• Rated for 600 volts and certified by CSA and UL Recognized.

Product Highlights

The C25DND340A features an efficient and reliable design, suitable for motor controls, solenoids, and various other high-power applications across diverse environments. Its compact size contributes to simpler mounting and maintenance procedures, offering enhanced convenience and reduced downtime.

Product Information

Standard Information

• Amperage: 40 Amp
• Enclosure Type: Open with metal mounting plate

Technical Specifications

• Coil Voltage: 110 to 120 VAC at 50/60 Hz
• Connection Type: Quick-connect
• Number of Poles: 3 Pole
• Operating Cycles: 300,000 cycles
• Operating Temperature: 150 degrees Fahrenheit
• Terminal Type: Screw/pressure plate and quick-connect terminals
