Eaton C25DND330H Definite Purpose Control Contactor 30A 277 Vac 60 Hz

Product Description

Eaton C25DND330H is a definite purpose control contactor designed for various industrial applications. This contactor operates at 277 VAC and 60 Hz, suitable for HVAC systems. It is non-reversing and can handle inductive loads of up to thirty amps and resistive loads of forty amps. The contactor features a quick-connect terminal design that allows for simple and fast installation.

• Voltage: 277 VAC
• Amperage: 30 Amp Inductive, 40 Amp Resistive
• Poles: Three Pole

Product Highlights

This Eaton contactor is ideal for heating, ventilation, air conditioning, and refrigeration applications. Its sturdy design ensures performance in demanding environments.

Product Information

Standard Information

• Catalog Number: C25DND330H
• Manufacturer: Eaton

Technical Specifications

• Frame Type: 15-50 A
• Connection Type: Quick-Connect (Side by Side)
• Enclosure Type: Open with Metal Mounting Plate
• Dimensions: 3.35 in L x 2.4 in W x 3.75 in H
• Weight: 1.05 lb
• Standards: CSA, UL Recognized
• Applications: Electrical Assemblies, Panels & EOEM
• UPC: 782116308897
