EATON C25DND330C CONTACTOR CTRL PRP DEFINITE 3 OPEN

Product Description

The Eaton C25DND330C is a non-reversing definite purpose control contactor with a coil voltage of four hundred forty to four hundred eighty volts at fifty to sixty hertz. It features a maximum load current of thirty amps inductive and forty amps resistive, configured with three poles. This contactor is suitable for various applications, particularly in heating, ventilation, air conditioning, and refrigeration systems.

• Voltage: Four hundred forty to four hundred eighty VAC at fifty or sixty Hz.
• Maximum current: Thirty amps inductive and forty amps resistive.
• Enclosure type: Open with metal mounting plate.

Product Highlights

The Eaton C25DND330C contactor is designed for industrial use, capable of handling substantial electrical loads reliably. Its quick-connect side-by-side connection type makes installation straightforward, while the pressure plate/screw terminal design ensures secure connections.

Product Information

Standard Information

• Model: C25DND330C
• Brand: Eaton
• Application: Electrical assemblies and panels, motor control

Technical Specifications

• Coil Voltage: 440 to 480 VAC at 50/60 Hz
• Maximum Load Current: 30 A Inductive / 40 A Resistive
• Number of Poles: 3
• Connection Type: Quick-Connect (Side by Side)
• Terminal Type: Pressure Plate / Screw
• Dimensions: 3.35 in L x 2.4 in W x 3.75 in H
• Enclosure Type: Open
• Standards: RoHS Compliant, UL Recognized, CSA Certified
