Eaton C0150E2A Type MTE Control Transformer 150 VA 240 x 480 Volt Primary 120 Volt Secondary

Product Description

The Eaton C0150E2A is a Type MTE Control Transformer designed to provide 150 VA power. It operates on primary voltages of 240 x 480, 230 x 460, and 220 x 440 volts with a secondary voltage of 120/115/110 volts. This transformer is ideal for machine tool control devices and industrial applications.

• Power rating: 150 VA
• Primary voltages: 240 x 480V, 230 x 460V, 220 x 440V
• Secondary voltage: 120/115/110V

Product Highlights

Engineered for high efficiency and reliable performance, the Eaton C0150E2A meets or exceeds ANSI/NEMA ST-1 requirements. It features copper windings and is encapsulated for protection in industrial environments.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Eaton

Technical Specifications

• Catalog Number: C0150E2A
• Power Rating: 150 VA
• Primary Voltage: 240 x 480V, 230 x 460V, 220 x 440V
• Secondary Voltage: 120/115/110V
• Temperature Rating: 55 degrees C
• Enclosure Material: Stainless Steel
• Weight: 5.3 lb
