EATON C0050E5E Type MTE Control Transformer With Fuse Clip 50 VA

Product Description

The EATON Control Transformer, MPN C0050E5E, is designed to provide stepped-down voltages to control circuits. It operates with a primary voltage of 240/480, 208/230/460, and 200/220/440 volts, connecting to secondary voltages of 23/110, 24/115, and 25/120 volts. This transformer is ideal for isolating control circuits from power and lighting circuits. Its robust design can handle various applications in industrial settings.

• Molded-in terminals enhance durability.
• Copper magnet wire increases efficiency.
• Epoxy encapsulated coils protect against moisture and contaminants.

Product Highlights

This transformer meets ANSI and NEMA standards, making it suitable for many industrial applications. It is rated at 50 VA and functions within a frequency range of 50/60 Hz. This model also supports safe operation by allowing the use of grounded or ungrounded circuits.

Product Information

Standard Information

• Manufacturer: EATON
• MPN: C0050E5E

Technical Specifications

• Type: MTE
• Power Rating: 50 VA
• Primary Voltage: 240/480, 208/230/460, 200/220/440 V
• Secondary Voltage: 23/110, 24/115, 25/120 V
• Temperature Rating: 55 °C
• Dimensions: 3.268 in L x 2.992 in W x 2.559 in H
• Housing Material: Silicon Steel
• Frequency Rating: 50/60 Hz
• Application: Industrial, Motor and Power Control Equipment
