Eaton BW2200 Type BW Plug-On Main Circuit Breaker, 120/240 VAC, 200 Amp, 10 kAIC, 2-Pole

Product Description

The Eaton BW2200 is a type BW plug-on main circuit breaker rated for 120/240 VAC and 200 amps with a 10 kA interrupt capacity. This two-pole circuit breaker is designed for use in a variety of electrical distribution applications, including as a main or emergency disconnect. It is compatible with wire sizes ranging from two AWG to 300 kcmil, ensuring flexibility in installation.

• 200 Amp rating for robust performance
• 10 kA interrupt rating to handle fault conditions
• Plug-on mounting for easy installation

Product Highlights

The Eaton BW2200 circuit breaker is essential for residential and commercial power distribution systems. Its thermal and magnetic trip mechanisms enhance safety by providing reliable overcurrent protection. This breaker is suitable for applications including renewable energy generation, conventional electrical systems, and marine vessels.

Product Information

Standard Information

• Type: Type BW
• Voltage Rating: 120/240 VAC

Technical Specifications

• Amperage Rating: 200 A
• Number of Poles: 2
• Interrupt Rating: 10 kA
• Trip Type: Thermal/Magnetic
• Mounting Type: Plug-On
• Dimensions: 6-1/4 in L x 5-1/4 in W x 5 in H
• Temperature Rating: 75 deg F
• Standards/Approvals: UL 489
• Country of Origin: Dominican Republic
