Eaton BRP115AF Type BR AFCI Combination Circuit Breaker, 120 VAC, 15 A, 10 kA Interrupt, 1 Poles

Product Description

Eaton BRP115AF Type BR AFCI Combination Circuit Breaker is designed for reliable protection in residential electrical systems. This circuit breaker operates at 120 volts and provides a current rating of 15 amps. It offers a quick and simple installation with a plug-on neutral feature for ease of use in load centers.

• Current Rating: 15 amps
• Voltage Rating: 120 VAC
• Interrupt Rating: 10 kA

Product Highlights

The Eaton BRP115AF is suitable for a range of electrical applications. It meets the requirements for the latest safety standards, ensuring effective protection against arc faults.

Product Information

Standard Information

• Manufacturer: Eaton
• Brand: Eaton

Technical Specifications

• Type: AFCI Combination Circuit Breaker
• Amperage Rating: 15 A
• Voltage Rating: 120 VAC
• Number of Poles: 1
• Interrupt Rating: 10 kA
• Wire Size: 14 to 8 AWG Cu/Al
• Connection: Plug-On
• Mounting Type: Pigtail
• Dimensions: 6 in L x 3-1/2 in W x 1-1/4 in H
• Standards/Approvals: UL Listed
