Eaton BRH120 1 Inch Type BR Plug-On Circuit Breaker 20 A 120/240 V

Product Description

The Eaton BRH120 is a thermal magnetic circuit breaker designed for residential application. It is a Type BR plug-on circuit breaker rated for twenty amps and can be used in standard load centers. This single-pole breaker supports a voltage of 120/240 volts and is compatible with wire sizes ranging from fourteen to four AWG. It features a twenty-two kA interrupt rating, ensuring a safe and efficient operation.

• Twenty amps maximum rating
• Single-pole configuration
• Plug-on mounting type

Product Highlights

The Eaton BRH120 is suitable for use in residential load centers, ensuring reliability and safety in electrical systems.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: BRH120

Technical Specifications

• Voltage Rating: 120/240 VAC
• Amperage Rating: 20 A
• Dimensions: 1 inch (L) x 2.8 inches (W) x 2.5 inches (H)
• Material: Thermoset
• Number of Poles: 1
• Interrupt Rating: 22 kAIC
• Mounting Type: Plug-On
• Country of Origin: Dominican Republic
