EATON BRDC220220 Type BRD Quadplex Circuit Breaker, 120/240 VAC, (4) 20 Amp, 10 kAIC

Product Description

The EATON BRDC220220 Type BR Quadplex Circuit Breaker is designed for use in residential load centers and panelboards. This breaker operates at 120/240 VAC, with four poles each rated at 20 amps. It has a 10 kA interrupt rating and offers common trip functionality, making it suitable for various applications.

• Four-pole configuration
• Compatible with 14 to 4 AWG copper or aluminum wire
• UL 489 certified for safe operation

Product Highlights

This circuit breaker is designed to prevent nuisance tripping with its thermal magnetic trip curve, and features a quick make, quick break mechanism for reliable performance.

Product Information

Standard Information

• Manufacturer: EATON
• Voltage Rating: 120/240 VAC

Technical Specifications

• MPN: BRDC220220
• Amperage Rating: 20 A
• Number of Poles: 4
• Interrupt Rating: 10 kA
• Wire Size: 14 to 4 AWG Copper/Aluminum
• Dimensions: 3 in L x 2 in W x 3 in H
• Temperature Rating: 60 to 75 deg C
• Application: Suitable for renewable energy generation and conventional energy systems
