Eaton BRDC215215 Type BR Quadplex Circuit Breaker 120/240 VAC (4) 15 Amp 10 kAIC

Product Description

The Eaton BRDC215215 is a Type BR Quadplex Circuit Breaker designed for 120/240 VAC applications. This breaker features four poles and is rated for (4) 15 Amp service with a ten kA Interrupt Rating. It is ideal for load centers and panelboards, providing reliable protection for electrical circuits.

• Type BR Quadplex design
• Designed for 120/240 VAC systems
• Four poles with a 10 kA interrupt rating

Product Highlights

Perfect for various applications in residential and commercial settings, the Eaton BRDC215215 can handle loads effectively. Suitable for both standard and thermal magnetic trip requirements.

Product Information

Standard Information

• Manufacturer: Eaton
• MPN: BRDC215215

Technical Specifications

• Voltage Rating: 120/240 VAC
• Amperage Rating: 15 A
• Number of Poles: 4
• Trip Type: Common/Thermal Magnetic
• Wire Size: 14 to 4 AWG
• Dimensions: 3 inches L x 2 inches W x 3 inches H
• Interrupt Rating: 10 kA
• Mounting Type: Plug-On
