EATON BRCAF120 Fire-Guard Combination Arc-Fault Circuit Breaker 120 VAC 20 A

Product Description

The EATON BRCAF120 is a fire-guard combination arc-fault circuit breaker designed for use in residential applications. This device features a voltage rating of 120 VAC and an amperage rating of 20 A, with a 10 kAIC interrupt rating. Its compact design allows for easy installation in 1 inch panels and supports various wire sizes from 14 to 4 AWG, copper or aluminum. The common trip feature enhances safety by ensuring that all poles trip together.

• Compatible with 14 to 4 AWG wire
• Plug-on mounting for simple installation
• Diagnostic version available for troubleshooting

Product Highlights

This circuit breaker features a diagnostic LED for easy troubleshooting, ensuring reliable operation in the field.

Product Information

Standard Information

• Brand: EATON
• MPN: BRCAF120

Technical Specifications

• Connection Type: Standard Pigtail
• Dimensions: 6 in L x 3-1/2 in W x 1-1/4 in H
• Mounting Type: Plug-On
• Temperature Rating: 60 to 75 deg C
• Type: Type BRC Combination
• Wire Size: 14 to 4 AWG Copper/Aluminum
• Voltage Rating: 120 VAC
• Amperage Rating: 20 A
• Interrupt Rating: 10 kAIC
• Number of Poles: 1
• Trip Type: Common
