Eaton BR240B Circuit Breaker 40A 2 Pole 120/240V AC

Product Description

Eaton BR240B is a thermal magnetic circuit breaker designed for use in residential applications. This 40 Amp, 2 pole circuit breaker operates on 120/240 Volt AC and features a common breaker trip. It is a plug-on type that fits standard load centers and panelboards.

• Rated for 10 kAIC interrupting capacity.
• Accepts wire sizes ranging from 14 to 4 AWG Copper or Aluminum.
• UL 489 and Federal Specifications W-C375 compliant.

Product Highlights

This circuit breaker is suitable for various applications, including residential wiring and renewable energy systems. Its plug-on design simplifies installation in load centers.

Product Information

Standard Information

• Brand: Eaton
• MPN: BR240B

Technical Specifications

• Voltage Rating: 120/240 Volt AC
• Amperage Rating: 40 Amp
• Number of Poles: 2
• Interrupt Rating: 10 kAIC
• Trip Type: Common breaker trip
• Mounting Type: Plug-On
• Wire Size Acceptable: 14-4 AWG
• Overall Dimensions: 3 inches Length x 2 inches Width x 3 inches Height
