Eaton BQC2402115 Type BD Quadplex 1-Inch CTL Plug-On Thermal-Magnetic Circuit Breaker, 240 VAC, (2) Single-Pole 15 Amp (1) Two-Pole 40 Amp, 10 kAIC, 4-Pole

Product Description

The Eaton BQC2402115 is a Type BQC thermal-magnetic circuit breaker designed for use in load centers. Rated for 240 VAC, it includes two single-pole connections at fifteen amps and one two-pole at forty amps. It has a standard interrupt rating of ten kA and utilizes a plug-on mounting style, suitable for various applications.

• Includes rejection tab feature for improved safety
• Designed for load center applications to prevent circuit overloads
• Meets UL 489 standards for reliability

Product Highlights

The Eaton BQC2402115 circuit breaker provides reliable protection against electrical faults, ensuring the safety of wiring within load centers.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: BQC2402115

Technical Specifications

• Type: Type BQC
• Voltage Rating: 120/240 VAC
• Amperage Rating: 15 to 40 A
• Number of Poles: 4
• Interrupt Rating: 10 kA
• Trip Type: Common/LI
• Wire Size: 14 to 4 AWG
• Dimensions: 3 in L x 2 in W x 3 in H
