EATON BQC230240 Type BQC Quadplex Circuit Breaker, 120/240 VAC, (1) 30 A, (1) 40 A, 10 kA Interrupt, 4 Poles

Product Description

The EATON BQC230240 Type BQC Quadplex Circuit Breaker is designed for efficient power distribution in electrical systems. Rated at 120/240 VAC, it includes one two-pole thirty amp and one two-pole forty amp circuit breaker integrated into a four-pole assembly with a ten kA interrupt rating. This circuit breaker offers thermal magnetic trip capabilities and is suitable for various installation environments.

• Includes one two-pole thirty amp and one two-pole forty amp.
• Features four poles for enhanced circuit protection.
• Designed for plug-on mounting, which simplifies installation.

Product Highlights

This circuit breaker provides essential protection for residential and commercial electrical systems by managing overloads and short circuits. It is suitable for various applications, including service entrances and load centers.

Product Information

Standard Information

• Manufacturer: EATON
• Model Number: BQC230240

Technical Specifications

• Voltage Rating: 120/240 VAC
• Amperage Rating: (1) 30 A, (1) 40 A
• Number of Poles: 4
• Interrupting Rating: 10 kAIC
• Trip Type: Common/Thermal Magnetic
• Mounting Type: Plug-On
• Wire Size: 14 to 4 AWG
• Overall Dimensions: 3 in L x 2 in W x 3 in H
• Temperature Rating: 600 to 750 degrees Celsius
