Eaton bl3-20 Conduit Fastener 1-1/4 Inch Emt Clip

Product Description

The EATON bl3-20 is a conduit-to-lathers channel clip designed to secure 1-1/4 inch EMT conduit to 1-1/2 inch strut channel. Manufactured as part of the Eaton B-Line series, this fastener provides a 50-pound load capacity and a zinc-plated finish for corrosion resistance. Dimensions are 1 inch height, 1 inch length, and 1 inch width, with a unit weight of 0.025 pounds. It is UL-listed for both the United States and Canada. Licensed electricians and electrical contractors install this fitting during conduit support and routing work in commercial and industrial construction.

The bl3-20 is used in electrical installations where EMT conduit must be anchored to lathers channel or standard 1-1/2 inch strut. Typical applications include suspended ceiling grid systems, exposed conduit runs in commercial buildings, and framing assemblies where conduit is routed parallel to or across channel strut. The clip is sold in a standard package of 100 per box, making it suitable for bulk rough-in work on larger projects. Made in the USA.

Key Features

• Secures 1-1/4 inch EMT conduit to 1-1/2 inch lathers channel strut
• 50-pound load capacity for reliable conduit support
• Zinc-plated finish provides corrosion resistance
• UL-listed for use in the United States and Canada
• Compact 1 inch x 1 inch x 1 inch profile fits tight spaces
• Sold 100 per box for high-volume rough-in applications

Compatibility

Designed as an OEM-style conduit fastener for 1-1/4 inch EMT conduit installations on 1-1/2 inch lathers channel strut systems.

Installation Notes

Installation is performed by licensed electricians in accordance with applicable NEC requirements for conduit support and spacing. Power down all circuits in the work area before securing conduit. Standard hand tools are sufficient for mounting; no special tooling is required. Verify that the strut channel is properly anchored to structure before attaching conduit clips.

Technical Specifications

• Conduit Size: 1-1/4 inches EMT
• Channel Size: 1-1/2 inches
• Load Capacity: 50 pounds
• Height: 1 inch
• Length: 1 inch
• Width: 1 inch
• Unit Weight: 0.025 pounds
• Finish: Zinc Plated
• Approval: UL (Canada and US)
• Standard Package: 100 per box
• Country of Origin: USA

Standard Information

• Brand: EATON
• Manufacturer Part Number: bl3-20
