Eaton BKD2G200 Type BKD Convertible Main/Sub-Feed Circuit Breaker Kit, 240 VAC, 200 Amp, 65 kAIC

Product Description

The Eaton BKD2G200 is a convertible main circuit breaker kit designed for both single-phase and three-phase applications. It operates at 240 volts and supports a current rating of 200 amps with a short-circuit interruption rating of sixty-five kiloamperes. This kit includes vital components such as circuit breakers, line terminals, and load bus connectors, making it suitable for various electrical assemblies or panels.

• 240 VAC, 200 Amp operation
• 65 kAIC rating
• Compatible with wire sizes ranging from #4 to 4/0 AI/Cu

Product Highlights

This kit is useful for electricians and contractors looking for reliable circuit protection in residential or commercial settings. The convertible design facilitates easy installation in different panelboard configurations.

Product Information

Standard Information

• Manufacturer: Eaton
• Type: Convertible Main Circuit Breaker Kit

Technical Specifications

• Amperage: 200 Amps
• Voltage: 240 VAC
• Short-Circuit Rating: 65 kAIC
• Catalog Number: BKD2G200
• Dimensions: 6 inches long x 4 inches wide x 3 inches high
• Country of Origin: United States
• Wire Range: AI/Cu (1) from #4 to 4/0
