Eaton B-Line N224SS6 Spring Nut, 1/4-In.-20, 1/4-In. Nut

Product Description

The EATON B-LINE N224SS6 is a spring nut with 1/4-in.-20 thread and a 1/4-in. nut, made of stainless steel. Designed for use with B22, B24, B26 and B32 aluminum channels. Channel nuts are designed to provide essential gripping power and ease during installation.

• 1/4-in.-20 thread
• 1/4-in. nut
• Made of stainless steel

Product Highlights

The EATON B-LINE spring nut provides essential gripping power and ease during installation.

Product Information

Standard Information

• Brand: EATON B-LINE
• Manufacturer Part Number: N224SS6
• Country of Origin: TW - Taiwan

Technical Specifications

• Manufacturer: EATON B-LINE
• Product Name: Eaton B-Line series spring nut
• Catalog Number: N224SS6
• UPC: 781011403348
• Product Length/Depth: 1.75 in
• Product Height: 0.85 in
• Product Width: 1.31 in
• Product Type: Spring nut
• Bolt/thread/rod size: 1/4"-20
• Product Category: Channel nuts
• Type: Nut with spring
• Load rating (pull out strength): 250 lbs
• Load rating (slip strength): 300 lbs
• Finish: Stainless steel type 316
• Material: Steel
• Thread Size: 1/4-20
• Exterior Finish: Stainless Steel
• Thread Type: Unified National Coarse (Unc)
• Thread Style: Unified National Coarse
• Thread Class: Class 2A
• Drive Style: External Hex
• Compatible Groove Diameter: 0.25 Inches
• Grade Rating: industrial
• Size Name: 1/4"
• Use With: B22/B24/B26/B32 Channel
• Fitting Type: Channel Spring Nut
• Hole Diameter: 1/4 in.
• No. of Holes: 1
• Applications: STRUT FITTINGS,BF-CHANNEL NUTS (BF)
• Size: 1/4 In-20 TPI
• Brand: B-Line
• Sub Brand: Bolted Framing
• 12-Digit UPC: 781011403348
• GTiN: 00781011403348
• Product UPC: 78101140334
• Height: 0.85 Inch
• Length: 1-3/4 Inch
• Diameter: 1/4 in
