EATON B-LINE 6A-06-90HB12 Horizontal Bend 90 deg 6 in W Tray 12 in Bend Radius

Product Description

The EATON B-LINE 6A-06-90HB12 is a horizontal bend made for ladder cable tray systems. This component is used to change the direction of cable runs at ninety degrees. The product is made from lightweight aluminum, suitable for both indoor and outdoor use. The design includes an I-Beam side rail that adds strength while reducing material usage.

• Constructed from marine-grade aluminum for durability
• Features a ninety-degree bend with a twelve-inch radius
• Compatible with B-Line series 2, 3, 4, and 5 cable tray fittings

Product Highlights

The EATON B-LINE 6A-06-90HB12 offers a reliable solution for cable management in any installation.

Product Information

Standard Information

• Material: Aluminum
• Origin: USA

Technical Specifications

• Angle: 90 deg
• Bend Radius: 12 in
• Tray Width: 6 in
• Height: 6 in
• Length: 18.0625 in
• Weight: 7.6 lbs/each
