Eaton AH460P9W Straight Blade Plug 60A 3-phase 250V

Product Description

The EATON AH460P9W is a heavy-duty straight blade plug rated for 60 amps at 250 volts in a 3-phase, 4-wire (3P4W) configuration. Designed for industrial and commercial electrical applications, this plug provides a secure, code-compliant termination point for high-amperage 3-phase circuits. It is installed by licensed electricians during equipment hookup, panel-fed circuit connections, or temporary power applications where a rugged, reliable connector is required. The 3P4W configuration supports grounded 3-phase loads, making it suitable for motors, HVAC equipment, and other demanding electrical loads.

This plug is appropriate for use in commercial and industrial settings where 3-phase 250-volt service is present. Typical installation scenarios include connecting large HVAC units, compressors, motors, and other 3-phase equipment to power distribution systems. It is commonly used in manufacturing facilities, mechanical rooms, and construction sites where portable or semi-permanent 3-phase connections are required.

Key Features

• 60-amp rating supports high-amperage 3-phase electrical loads
• 250-volt rating suitable for standard commercial 3-phase service
• 3-pole, 4-wire (3P4W) configuration provides grounded 3-phase connectivity
• Straight blade design for direct, secure plug-in connections
• Heavy-duty construction built for industrial and commercial environments

Compatibility

Designed as an OEM-style replacement or direct-use straight blade plug for 3-phase, 4-wire, 250-volt electrical systems rated at 60 amps.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize and lock out the circuit at the panel before making any wiring connections to this plug. Verify that the supply circuit ampacity and voltage match the plug ratings of 60 amps and 250 volts before energizing. Use appropriate wire gauge for the 60-amp circuit as specified by NEC ampacity tables.

Technical Specifications

• Amperage: 60 amps
• Voltage: 250 volts
• Phase Configuration: 3-phase
• Wiring Configuration: 3P4W (3-pole, 4-wire)
• Connector Type: Straight blade plug
• Package Dimensions (L x W x H): 11.5 inches x 5.12 inches x 5.12 inches
• Weight: 1.96 pounds
• UPC: 04089361984

Standard Information

• Brand: EATON
• Manufacturer Part Number: AH460P9W
