Eaton AH460C7W Connector 3P4W 60A 277/480V

Product Description

The EATON AH460C7W is a 3-phase, 4-wire twist-lock connector rated for 60 amps at 277/480 volts. Designed for industrial and heavy commercial electrical distribution, this connector provides a secure, locking connection that resists accidental disconnection under load. It is typically installed by licensed electricians in applications requiring high-voltage, high-amperage power delivery to equipment such as HVAC systems, industrial machinery, and large lighting systems. The locking blade design ensures a reliable mechanical and electrical connection in demanding service environments.

This connector is suited for use in 3-phase, 4-wire electrical systems operating at 277/480 volts where 60-amp capacity is required. Common applications include commercial building electrical panels, industrial equipment hookups, and temporary or permanent power connections in facilities requiring NEMA-style locking connectors. It is appropriate for both new installations and replacement of existing connectors in like-rated circuits.

Key Features

• 60-amp rating supports high-amperage industrial and commercial loads
• 277/480-volt rating covers standard 3-phase commercial service voltages
• 3-phase, 4-wire (3P4W) configuration for full line-to-line and line-to-neutral connectivity
• Twist-lock design prevents accidental disconnection under load
• Compact form factor at 11.5 inches x 5.12 inches x 5.12 inches

Compatibility

Designed as an OEM-style replacement connector for 3-phase, 4-wire electrical systems rated at 60 amps and 277/480 volts requiring a twist-lock connection interface.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the circuit at the panel before beginning any wiring work. Verify that the circuit rating matches the connector's 60-amp, 277/480-volt specifications before installation. Do not exceed the rated amperage or voltage of this connector.

Technical Specifications

• Amperage: 60 amps
• Voltage: 277/480 volts
• Configuration: 3-Phase, 4-Wire (3P4W)
• Dimensions (L x W x H): 11.5 inches x 5.12 inches x 5.12 inches
• Weight: 2.09 pounds
• UPC: 04089361980

Standard Information

• Brand: EATON
• Manufacturer Part Number: AH460C7W
