Product Description
The Eaton A1X1PK is an auxiliary switch designed for Type F-frame HMCP circuit breakers. This product provides an effective means of adding additional functionality to your circuit breaker system. It is factory installed and connects using pigtail leads.
- Suitable for Type F-frame HMCP breakers
- Includes pigtail leads for easy connection
- Mounting orientation options: left, right, or neutral
Product Highlights
This auxiliary switch is ideal for various applications including commercial and institutional buildings. It enhances the performance and capabilities of Eaton's molded case circuit breaker systems.
Product Information
Standard Information
Technical Specifications
-
Voltage Rating: 600 VAC, 125/250 VDC
-
Contact Configuration: 1A-1B
-
Dimensions: 2.9 inches Length x 5.5 inches Width x 3.2 inches Height
-
Application: Suitable for commercial and institutional buildings
-
Connection Type: Pigtail leads
-
Amperage Rating: 50 A
