Eaton 8170A-6501 Photoelectric Sensor

Product Description

The EATON 8170A-6501 is a photoelectric sensor designed for industrial and commercial detection applications. Photoelectric sensors use a light beam to detect the presence, absence, or position of objects without physical contact. This type of device is commonly installed in control panels, conveyor systems, automated equipment, and building automation setups. Licensed electricians and industrial controls technicians are the primary installers. At 3.55 pounds, the unit carries enough build quality for demanding environments while remaining straightforward to wire into a standard control circuit.

The 8170A-6501 suits applications where non-contact object detection is required. Typical installations include automated production lines, access control points, material handling equipment, and commercial facility management systems. It is appropriate for both new installations and replacement of existing photoelectric detection units in similar control system configurations.

Key Features

• Photoelectric detection technology for non-contact object sensing
• Suitable for industrial and commercial control system integration
• Solid construction supporting demanding installation environments
• Compatible with standard control circuit wiring practices

Compatibility

Designed as an OEM-style replacement or direct-fit photoelectric sensor for industrial and commercial control system applications where EATON sensing components are specified.

Installation Notes

Installation should be performed by a licensed electrician or qualified controls technician in accordance with applicable NEC requirements. Disconnect and lock out all power to the control circuit before removing the existing sensor or making any wiring connections. Verify sensor alignment and detection range after installation before returning the system to service.

Technical Specifications

• Weight: 3.55 pounds
• UPC: 78211382733

Standard Information

• Brand: EATON
• Manufacturer Part Number: 8170A-6501
