Eaton 5ACLS-9R Bussmann series 5ACLS fuse, Single barrel, 9R designation, 4.8 kV, 200A, 50 kAIC, Motor start, ACLS, Class R, Ampgard, Single barrel

Product Description

Eaton 5ACLS-9R is a current-limiting medium voltage fuse that provides backup protection suitable for both indoor and outdoor applications. This fuse is designed to limit short-circuit currents in high-capacity systems and is commonly used to protect medium voltage drives and starters.

• Rated for 200 amperes and 4.8 kilovolts.
• Includes open fuse indication for quick troubleshooting.
• Available in ferrule and bolt-on models.

Product Highlights

This fuse is designed to be used with medium voltage drives, ensuring that system integrity is maintained during high fault conditions.

Product Information

Standard Information

• Brand: Eaton
• Catalog Number: 5ACLS-9R

Technical Specifications

• Voltage Rating: 4.8 kV
• Amperage Rating: 200 A
• Interrupt Rating: 50 kA
• Application: Medium voltage drives and starters
• Special Features: Single barrel, 9R designation
• Country of Origin: Dominican Republic
• Sub Brand: Bussmann Series
• Mounting Type: Ampgard
