Eaton 505C633G01 Ac Type 2 Overload Relay

Product Description

The EATON 505C633G01 is an AC Type 2 overload relay designed to protect motors and electrical circuits from sustained overcurrent conditions. This device monitors current draw and trips to interrupt the circuit when load levels exceed safe operating thresholds, preventing motor burnout and equipment damage. It is a compact unit measuring 4.8 inches by 2.9 inches by 1.5 inches and weighing 0.95 pounds, making it suitable for panel and enclosure mounting in commercial and industrial electrical applications. Licensed electricians and industrial maintenance technicians are the primary installers of this type of protective relay component.

The 505C633G01 is suited for motor control and protection circuits in commercial and industrial settings. AC Type 2 overload relays of this class are commonly installed in motor starter assemblies, control panels, and MCC buckets where reliable overcurrent protection is required. This relay is appropriate for use in applications where the motor circuit demands a coordinated overload protection device that meets Type 2 coordination requirements under applicable standards.

Key Features

• AC Type 2 coordination rating for motor overload protection
• Compact form factor: 4.8 inches x 2.9 inches x 1.5 inches
• Lightweight construction at 0.95 pounds for easy panel integration
• Designed to interrupt overcurrent conditions and protect downstream motor windings
• UPC: 78667882143

Compatibility

Designed as an OEM-style replacement or direct-fit overload relay for AC motor starter and control panel assemblies requiring Type 2 overload coordination.

Installation Notes

Installation of overload relays should be performed by a licensed electrician in accordance with the NEC and applicable local codes. De-energize and lock out the panel or motor control center before removing or installing this relay. Verify that current range settings match the full-load amperage of the protected motor before returning the circuit to service. Do not bypass or jumper the overload relay contacts during testing.

Technical Specifications

• Type: AC Type 2 Overload Relay
• Length: 4.8 inches
• Width: 2.9 inches
• Height: 1.5 inches
• Weight: 0.95 pounds
• UPC: 78667882143

Standard Information

• Brand: EATON
• Manufacturer Part Number: 505C633G01
