Eaton 3BR3042L200R 208 Star/120/240 VAC 200 Amp 3-Phase 4-Wire Main Lug Load Center

Product Description

The Eaton 3BR3042L200R is a commercial load center designed for electrical distribution in residential and commercial settings. This model operates at 208Y/120 or 240 volt and comes with a 200-amp rating. It features a main lug design with no feed-thru lugs and can support up to 42 circuits with 30 spaces available for breakers.

• 200 amps rating suitable for high-demand applications
• Accommodates wiring sizes from 1 AWG to 300 kcmil
• NEMA 3R enclosure for outdoor installations

Product Highlights

This load center is ideal for handling multiple circuits efficiently, providing a robust solution for commercial electrical installations.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: 3BR3042L200R

Technical Specifications

• Voltage Rating: 208Y/120, 240V
• Amperage Rating: 200 A
• Enclosure Type: NEMA 3R
• Dimensions: 3.88 inches (L) x 14.31 inches (W) x 39 inches (H)
• Number of Circuits: 42
• Number of Spaces: 30
• Interrupt Rating: 25 kAIC
• Wiring Configuration: 4-Wire
• Made in USA: Yes
