Eaton 2092-2-2S Pipe Tee 1/8 in Mnpt X Fnpt Stainless 10000 Psi

Product Description

The EATON 2092-2-2S is a stainless steel industrial pipe tee designed for high-pressure fluid and gas line applications. Configured with a 1/8 inch male NPT run connection and two 1/8 inch female NPT branch connections, it allows a single pressure line to split into two downstream paths or accept an inline branch tap. The fitting is rated to 10,000 psi maximum working pressure and handles temperatures from -65 degrees F to 400 degrees F. Stainless steel construction resists corrosion in aggressive media and harsh service environments. Licensed plumbers, pipefitters, and industrial maintenance technicians are the primary installers.

This tee is suited for residential and commercial high-pressure instrumentation lines, hydraulic systems, pneumatic circuits, and compressed gas distribution where a compact 1/8 inch NPT branch connection is required. The MNPT x FNPT x FNPT configuration allows the fitting to thread directly into a female-ported manifold, valve body, or gauge port on the male run end while accepting two female-threaded lines on the branch ports. It conforms to SAE 140424 standards, making it appropriate for OEM assemblies and field service work that specifies SAE-rated fittings.

Key Features

• 10,000 psi maximum working pressure for demanding high-pressure service
• Stainless steel construction provides corrosion resistance in aggressive fluid and gas environments
• MNPT x FNPT x FNPT configuration enables direct manifold or valve-body installation on the male run end
• Wide temperature range: -65 degrees F to 400 degrees F
• Meets SAE 140424 standards for use in OEM and field-service applications
• Compact 1/8 inch thread size suits instrumentation, gauge, and pilot-line installations

Compatibility

Designed as an OEM-style and field-service replacement tee for high-pressure hydraulic, pneumatic, and instrumentation piping systems using 1/8 inch NPT threaded connections.

Installation Notes

Installation should be performed by a licensed pipefitter or qualified maintenance technician familiar with high-pressure piping systems. Depressurize and isolate the line completely before removing any fitting. Apply thread sealant rated for the service pressure and media type; follow the applicable piping code — ASME B31.1 or B31.3 as appropriate — for assembly and leak-test requirements. Do not exceed the rated working pressure or temperature listed for this fitting.
