Eaton 2027-6-6S Female Jic 37 Swivel Union 0.38in Od

Product Description

The EATON 2027-6-6S is a female JIC 37-degree swivel union fitting designed for hydraulic hose assemblies. Machined from steel with a straight, threaded connection type, this fitting joins two hose ends or components using a 9/16-18 thread and accepts hose with a 0.38-inch outside diameter. It has a rated maximum working pressure of 5,000 psi and an overall installed length of 1.41 inches. The swivel design allows the fitting to rotate during assembly, reducing hose twist and simplifying installation in tight routing situations. It is specified to SAE J514 standards and is suited for professional installation by hydraulic technicians and fluid power specialists.

This fitting is used in high-pressure hydraulic lines where a leak-free JIC 37-degree flare connection is required at a union point. Typical applications include chemical processing systems, hydraulic power units, and instrumentation lines. The straight body profile makes it appropriate for in-line routing where angular adapters are not needed. It is sold individually and is a direct-use component requiring no additional hardware for standard hose assembly work.

Key Features

• Female JIC 37-degree swivel union end form for leak-free flare-seat connections
• Rated to 5,000 psi maximum working pressure
• 9/16-18 thread size with straight body shape
• 0.38-inch hose outside diameter compatibility
• Steel construction for durability in hydraulic service
• Meets SAE 070101 and SAE J514 standards

Compatibility

Designed for use in chemical processing systems, hydraulic circuits, and instrumentation applications requiring a JIC 37-degree female swivel union connection per SAE J514.

Installation Notes

Installation should be performed by a qualified hydraulic technician or fluid power specialist. Depressurize and bleed the hydraulic system fully before removing or installing any fittings. The swivel feature allows hand-alignment before final torque — do not use the swivel to compensate for misaligned hose routing under pressure. Inspect the flare seat and threads for damage before assembly and follow SAE J514 assembly practices for JIC fittings.
