Eaton 14150RD14 OEM Prism 18mm tubular photoelectric sensor

Product Description

The EATON 14150RD14 is an OEM Prism 18mm tubular photoelectric sensor. This sensor features a right angle, a 15 ft distance, and an isolated solid-state relay with 80 mA at 132 Vac/110 mA at 132Vdc. It includes a 6.6 ft (2m) cable and a 20–132 Vac/15-30 Vdc input, current limited for loads > 32V AC/DC.

• Features an isolated solid-state relay
• Includes a 6.6 ft (2 m) cable
• Current limited for loads greater than 32V AC/DC

Product Highlights

The EATON 14150RD14 photoelectric sensor is suitable for various industrial automation and control applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: 14150RD14
• Country of Origin: Mexico

Technical Specifications

• SKU: 14150RD14
• Product Name: Eaton OEM Prism 18mm tubular photoelectric sensor
• Catalog Number: 14150RD14
• UPC: 782113011097
• Product Length/Depth: 0.47 in
• Product Height: 2.75 in
• Product Width: 0.71 in
• Product Weight: 0.2875 lb
• Warranty: 3 year
• Compliances: CE Marked
• Certifications: cUL Recognized UL Recognized
• Catalog Notes: For complete system; order sensor and retroreflector. Retroreflector not included
• Product Type: Tubular photoelectric sensor
• Contact Rating: 80 mA at 132 Vac / 110 mA at 132Vdc
• Cable type: Polyvinyl Chloride (PVC)
• Enclosure material: Cable jacket: PVC Body: structural polyurethane foam Lens: polycarbonate
• Operating mode: Non polarized retroreflective
• Connection: 6.6 ft (2 m) cable
• Contact configuration: Isolated solid state relay
• Sensor type: Retroreflective
• Switch type: Photoelectric
• Input Voltage: 20-132 Vac, 15-30 Vdc
• LED indicator: Output status: red
• Protection: Current limited for loads less than 32 Vac/dc
• Cord length: 79.2 ft
• Maximum AC current: 80 mA
• Maximum DC current: 110 mA
• Operating Temperature - max: 131 °F
• Operating Temperature - min: -13 °F
• Environmental rating: NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13
• Brand: Eaton
• Manufacturer Part Number: 14150RD14
• Unit of Measure: EA
• Country of Origin: Mexico
• Made in USA: No
• Application: Vehicles: On-Road - PickUp & Delivery: Food
• Standard: cUL Recognized,UL Recognized,Contact Manufacturer,CE Marked
• GTIN: 00782113011097
• Item Type: Tubular photoelectric sensor
• Operating Temperature: -13 Degrees to 131 Degrees F (-25 Degrees to 55 Degrees C)
• Output Configuration: Relay
• Manufacturer: Eaton Electrical
• Light Source: Red LED
• Series: OEM Prism
• Connection Method: Cable
• Packaging: Bulk
• Ingress Protection: NEMA 1, 3, 4, 4X, 6, 6P, 12, 13
• Part Status: Active
• Cable Length: 78.74" (2m)
• Sensing Method: Retroreflective
• Adjustment Type: Adjustable
• Sensing Distance: 15" (4.57m)
