Eaton 14100A6517 Comet 18mm tubular photoelectric sensor

Product Description

The Eaton 14100A6517 Comet 18mm tubular photoelectric sensor is designed for forward viewing with a sensing distance of 25 feet. This retroreflective sensor operates at 10-30 Vdc and includes a 6.6 ft cable. It features NPN and PNP open collector outputs and offers protection against short circuits.

• Non polarized retroreflective operation
• Auto reset short circuit protection
• NPN and PNP open collector outputs

Product Highlights

The Eaton Comet series photoelectric sensor has a polyurethane housing that provides shock and vibration resistance. Visible beam models allow for easy sensor alignment.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: 14100A6517

Technical Specifications

• SKU: 14100A6517
• Product Name: Eaton Comet 18mm tubular photoelectric sensor
• Catalog Number: 14100A6517
• UPC: 782113824444
• Product Length/Depth: 0.47 in
• Product Height: 2.6 in
• Product Width: 0.71 in
• Product Weight: 0.2875 lb
• Warranty: 3 year
• Compliances: CE Marked
• Certifications: UL Recognized cUL Recognized
• Catalog Notes: Retroreflector not included. Ranges based on a 3-inch diameter retroreflector. For complete system; order sensor and retroreflector.
• Product Type: Tubular photoelectric sensor
• Contact Rating: 100 mA PNP, 250 mA NPN at 10-30 Vdc
• Cable type: Polyvinyl Chloride (PVC)
• Enclosure material: Cable jacket: PVC Body: structural polyurethane foam Lens: polycarbonate
• Operating mode: Non polarized retroreflective
• Connection: 6.6 ft (2 m) cable
• Contact configuration: NPN and PNP open collector
• Sensor type: Retroreflective
• Switch type: Photoelectric
• Input voltage: 10-30 Vdc
• LED indicator: Output status: red
• Protection: Auto reset short circuit
• Cord length: 79.2 ft
• Maximum DC current: 100 mA PNP, 250 mA NPN
• Operating temperature - max: 158 °F
• Operating temperature - min: -40 °F
• Environmental rating: NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K
• Brand: Eaton - Cutler Hammer
• UNSPSC Code: 41110000
• Range: 25 ft
• Volts DC Range: 10 - 30
• Manufacturer: Eaton
• Product Series: COMET
• Family Series: Eaton Photoelectric Sensors, COMET Series
• Description: Eaton Comet 18mm tubular photoelectric sensor, Forward Viewing, Sensor dist 25 Ft, 100 mA PNP, 250 mA NPN max DC, NPN/PNP Open coll, 100 mA PNP, 250 mA NPN at 10-30 Vdc, 6.6 Ft.2m Cable, Non Polarized Retroreflective, 6.6 Ft.2m
• Power Type: DC
• Beam Type: Infrared
• Max Range: 25 '
• Voltage: 10-30 VDC
• Nominal Voltage: 12 VDC, 24 VDC
• Connection Type: Cable
• Operating Mode: Dark On, Light On
• Output Type: PNP/NPN
• Max Load Current: 0.25 A
• Composition: Non-Metallic
• Protection Rating: NEMA 1, NEMA 2, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13
• Approvals: CE, cUL, UL
• Net Weight: 0.2875 lbs
• Gross Weight: 0.2875 lbs
• Type: Photoelectric Reflex Sensor
• Sensing Range: 25 ft. (7.6m)
• Output Configuration: NPN and PNP
• Connection Size: 6 ft.
• Sensing Position: End
• Response Time: 1ms
• Material: Polyurethane Foam (RIM)
• Enclosure Rating NEMA: NEMA 1, 3, 4, 4X, 6, 12, 13
• Enclosure Rating IEC: IEC IP69K
• Temperature Rating: -40° to +158°F (-40° to +70°C)
• Temperature Rating - min: -40°F (-40°C)
• Temperature Rating - max: 158°F (70°C)
• Beam Configuration: 1 in. diameter at 50 in. (25mm at 1.3m)
• Wires - Voltage Type: 3 and 4 Wire DC
• Nominal Dimensions: LxWxH: 2.20 x 0.47 x 0.71 in.
• Load Current - max: 300 mA
• Housing Material: Polyurethane Foam (RIM)
