Eaton 12Z-672-BG Hydraulic Hose Female Jic Swivel 90 Elbow

Product Description

The EATON 12Z-672-BG is a Female JIC Swivel 90-Degree Elbow hydraulic hose fitting manufactured from steel. It connects hydraulic hose assemblies to JIC-threaded ports at a 90-degree angle, reducing stress on hose runs and allowing cleaner routing in tight equipment layouts. The fitting features a 0.75 inch inside diameter, a 1-1/16-12 thread size, and a flanged shaft type. It is compatible with SAE J1176 standards and suits applications where space constraints require an angled connection rather than a straight fitting. Licensed hydraulic system technicians and equipment mechanics are the typical installers.

This fitting is used in mobile hydraulic equipment, industrial machinery, and fluid power systems where hose assemblies must transition to a 90-degree angle at a threaded port. The Z-series designation places it within EATON's replacement and service fitting line. The threaded connection type and flanged construction make it appropriate for high-pressure hydraulic circuits in both OEM and aftermarket service contexts. It is sold individually and is suitable for new assembly builds as well as field repair applications.

Key Features

• Female JIC swivel design allows 90-degree hose routing without twisting the hose body
• 1-1/16-12 thread size matches standard JIC hydraulic port sizing
• 0.75 inch hose inside diameter accommodates -12 hose sizes
• Steel construction provides durability in high-pressure hydraulic service
• Flanged shaft type for positive seating and alignment
• Meets SAE J1176 standard for hydraulic hose fittings

Compatibility

Compatible with the following EATON hose series and part families: EC110, EC115, EC118, EC210, EC215, H0105 (-06 thru -12, -20), H0106 (-04 thru -10), H104, H115 (-04 thru -20), H116 (-04, -06, -08), H145, H145R, H1571 (-12 only), H1776 (-04 thru -20), H1777 (-04, -06, -08), H1812 (-04 thru -20), H190, H190H, and H1981 (-04).

Installation Notes

Installation should be performed by a qualified hydraulic technician familiar with JIC swivel fitting assembly procedures. Depressurize and de-energize the hydraulic system fully before removing any existing fittings or hose assemblies. Inspect thread condition on both the fitting and the port before installation, and verify the swivel moves freely after assembly. Follow applicable SAE J1176 torque and assembly guidance for JIC swivel fittings to prevent leaks or joint failure.
