Eaton 112 Arrow Hart��� Duplex Tamper/Weather-Resistant Straight Blade Receptacle 125/250 VAC 50 A

Product Description

The Eaton 112 Arrow Hart��� Duplex Tamper/Weather-Resistant Straight Blade Receptacle is designed for commercial and industrial power connectivity. This receptacle supports 125/250 VAC, 50 A, and features a heavy-duty design. It is ideal for high-amperage applications and is NEMA 10-50 configured with 3 poles and 3 wires.

• Heavy duty design and construction
• Ideal for high amperage industrial or commercial power connectivity application
• For replacement use in older homes with 3-wire range and dryer connection points

Product Highlights

Durable receptacle for industrial and commercial applications requiring high amperage and robust construction.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: 112

Technical Specifications

• Amperage Rating: 50 A
• Voltage Rating: 125/250 VAC
• Poles: 3
• Wires: 3
• Type: Duplex Tamper/Weather-Resistant Straight Blade Receptacle
• NEMA Configuration: 10-50
• Color: Black
• Grade: Commercial
• Temperature Rating: -4 to 158 deg F
• Material: Nylon
• Vendor SKU: 112
• UPC: 032664196409
• UNSPSC: 39121406
• Standard & Approvals: CSA Certified, NOM Certified, RoHS Complaint, UL 498
• Manufacturer: EATON
• Brand: EATON
• Compliances: RoHS Compliant NAFTA
• Certifications: UL Listed NOM
• Product Type: Power device receptacle
• Used with: S80
• Special features: Range
• Wiring method: Back and bottom
• Mounting method: Flush
• Connection type: Screw
• Style: Power
• Allowable wire size: #12-4 AWG
• Torque rating: 25 lbf-inch
• Design type: Receptacle
• Receptacle type: Three-pole, three-wire, non grounding
• Body Cover Material: Nylon
• Cable/Wire Size: 10 AWG [min], 4 AWG [Max]
• Operating Temperature: 75 deg C
• Wire Size: 4 AWG
• Suitable for: 80 Power Plug
• Number Of Poles: 3
• Number of Wires: 3
