Eaton 10316h1097 Precision Limit Switch 600V Cross Roller

Product Description

The EATON 10316h1097 is a Type PS Heavy Duty Precision Limit Switch rated for 600 VAC/VDC service in demanding industrial environments. Part of the 10316 Series, this limit switch uses a cross roller plunger actuator to deliver reliable position sensing and control signaling in machine, conveyor, and safety system applications. The steel body with zinc plated finish provides corrosion resistance and long service life. At 1/2 hp power rating and 600 volts, it is built to handle the electrical loads common in industrial control panels and automated machinery. Licensed electricians and industrial control technicians are the primary installers.

This limit switch is designed for use in industrial facilities, factories, and safety and security systems. It serves a variety of special-purpose industrial applications including MRO maintenance and user replacement scenarios. The cross roller plunger actuator is suited for installations where consistent mechanical actuation is required, such as end-of-travel detection on automated equipment or machine guarding circuits. Its heavy-duty Type PS construction is intended for environments where standard-duty switches would be insufficient.

Key Features

• 600 VAC/VDC voltage rating for high-demand industrial control circuits
• Cross roller plunger actuator for precise, repeatable mechanical actuation
• 1/2 hp power rating supports motor control and heavy electrical loads
• Steel construction with zinc plated finish for corrosion resistance
• Type PS Heavy Duty classification for demanding factory and industrial environments
• Compact form factor at 0.81 x 1.53 x 2.5 inches for tight panel and machine installations

Compatibility

Designed as an OEM-style replacement for Type PS Heavy Duty precision limit switches in industrial control and safety system applications where 600 VAC/VDC cross roller plunger actuators are specified.

Installation Notes

Installation should be performed by a qualified electrician or industrial controls technician in accordance with applicable NEC requirements and local codes. De-energize and lock out the circuit before removing the existing switch or wiring the replacement. Verify actuator alignment with the mechanical trip point before restoring power to avoid false actuation or missed signals. Do not exceed the rated voltage or power values for this switch.

Technical Specifications

• Series: 10316
• Type: Type PS Heavy Duty
• Voltage Rating: 600 VAC/VDC
• Power Rating: 1/2 hp
• Actuator: Cross Roller Plunger
• Length: 0.81 inches
• Width: 1.53 inches
• Height: 2.5 inches
• Material: Steel
• Finish: Zinc Plated
• UNSPSC: 39122213

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10316h1097
