Eaton 10250TS80 Standard Type Pilot Light Lens

Product Description

The EATON 10250TS80 is a standard-type pilot light lens designed for use with 30.5mm operator devices in industrial control and panel applications. This small-format lens fits into the 10250T series pilot light assembly, providing a clear or colored light diffusion window that allows operators to read indicator status at a glance. Licensed electricians and panel builders install this lens as part of a complete pushbutton or pilot light assembly. At 1.7 inches long by 1.7 inches wide and just 0.1 inches thick, it installs directly into the matching 10250T series operator housing with no tools required beyond hand pressure.

The 10250TS80 is suited for industrial control panels, machine tool stations, and operator interface enclosures requiring 30.5mm pilot light assemblies. It is a direct component of the EATON 10250T series, which is widely used in manufacturing, process control, and heavy equipment applications. Panel builders and maintenance electricians working on industrial machinery will encounter this lens as a service or replacement part when refurbishing or repairing existing pilot light assemblies.

Key Features

• Standard-type lens fits 30.5mm 10250T series pilot light assemblies
• Low-profile design at 0.1 inches thick for flush-panel installation
• Compact 1.7 x 1.7 inch footprint matches standard 10250T operator cutout
• Lightweight at 0.01 pounds for easy handling during panel assembly
• Designed as a direct component replacement within the 10250T series assembly

Compatibility

Designed as an OEM-style replacement lens for 30.5mm pilot light assemblies in the EATON 10250T series operator device family.

Installation Notes

Installation is performed by qualified electricians during panel assembly or field service of industrial control stations. De-energize the control panel and follow applicable NFPA 70E lockout/tagout procedures before servicing any pilot light assembly. The lens seats into the operator housing by hand and should be inspected for cracks or distortion before reinstallation. Do not use solvents on the lens surface, as this may cause crazing or reduced light transmission.

Technical Specifications

• Series: 10250T Standard Type
• Operator Size: 30.5mm
• Length: 1.7 inches
• Width: 1.7 inches
• Height (Thickness): 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211336081

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS80
