Eaton 10250TS74 Standard Type Pilot Light Lens

Product Description

The EATON 10250TS74 is a standard-type pilot light lens designed for use with 30.5mm diameter indicator light and pushbutton assemblies in industrial control applications. This lens mounts to the front of a compatible operator housing and provides a colored or clear window for lamp visibility on control panels, motor control centers, and operator stations. At 1.7 inches by 1.7 inches with a depth of 0.1 inches and a weight of 0.01 pounds, it is a compact, lightweight replacement component that electricians and panel builders install during new builds or field service.

This lens is suited for industrial control panels, machine tool stations, and motor control centers where 30.5mm pilot devices are installed. It is appropriate for both new panel construction and replacement service on existing operator assemblies. Applications include manufacturing facilities, process control environments, and commercial electrical equipment where clear, reliable indicator light components are required.

Key Features

• Standard-type lens designed for 30.5mm pilot light and pushbutton assemblies
• Compact profile at 1.7 inches by 1.7 inches by 0.1 inches for low-clearance panel installations
• Lightweight construction at 0.01 pounds minimizes added load on operator hardware
• Direct OEM-style replacement for compatible EATON 10250T series operator assemblies

Compatibility

Designed as an OEM-style replacement lens for 30.5mm standard-type pilot light and pushbutton operator assemblies in industrial control panel applications.

Installation Notes

Installation is performed by licensed electricians or qualified panel builders. De-energize the control panel and verify the absence of voltage before servicing any pilot device assembly. The lens typically snaps or threads onto the front of the operator body and requires no special tools. Follow applicable NEC requirements for industrial control panel service and assembly.

Technical Specifications

• Series: 10250T Standard Type
• Mounting Diameter: 30.5mm
• Dimensions (L x W x H): 1.7 inches x 1.7 inches x 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211336079

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS74
