Eaton 10250TS73 Standard Pushbutton Operator 30.5mm

Product Description

The EATON 10250TS73 is a standard-type pushbutton operator designed for use in industrial control panels and operator interface stations. Built to the 30.5mm mounting standard, this operator fits into standard cutout panel holes and works with compatible 10250T-series contact blocks and legend plates to form a complete pushbutton assembly. Licensed electricians and industrial control panel builders install this type of component during new panel construction or during operator replacement in existing automation and motor control circuits. The compact profile keeps panel face space to a minimum while providing reliable operator actuation.

The 10250TS73 is suited for industrial, commercial, and light manufacturing environments where 30.5mm pushbutton stations are specified. It is commonly installed in motor control centers, machine control enclosures, and operator interface panels. This operator is the field-replaceable actuator component in a modular pushbutton assembly, allowing the operator head to be swapped independently of the contact block without disturbing field wiring.

Key Features

• 30.5mm mounting diameter fits standard industrial panel cutouts
• Standard-type operator head for use in modular 10250T-series assemblies
• Compact body measures 1.7 inches x 1.7 inches x 0.1 inches for minimal panel depth
• Lightweight construction at 0.01 pounds for easy panel handling and installation
• Modular design allows operator replacement without rewiring contact blocks

Compatibility

Designed as an OEM-style replacement or new-installation operator for 30.5mm industrial pushbutton assemblies in the EATON 10250T series product family.

Installation Notes

Installation of pushbutton operators in control panels is typically performed by a licensed electrician in accordance with NFPA 70 (NEC) Article 430 and applicable machine safety standards. De-energize and lock out the control panel before beginning any operator replacement work. The operator head mounts into the panel cutout and secures to the contact block per the assembly instructions for the specific 10250T-series configuration in use. Do not overtighten the mounting hardware, as the operator body is compact and designed for hand-tool installation.

Technical Specifications

• Mounting Diameter: 30.5mm
• Dimensions (L x W x H): 1.7 inches x 1.7 inches x 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211336078

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS73
