Eaton 10250TS54 Standard Push Button Operator 30.5mm

Product Description

The EATON 10250TS54 is a standard-type push button operator in the 30.5mm mounting class, designed for use in industrial control panels and operator interface stations. Push button operators serve as the mechanical interface between a technician or machine operator and the control circuit, initiating commands such as start, stop, or emergency functions. The 10250TS54 fits into the 10250T series operator platform, providing a reliable momentary or maintained actuation point for low-voltage control wiring. Installation is performed by licensed electricians or qualified industrial maintenance technicians working on motor control centers, switchgear, or panel-mounted control assemblies.

This operator is suited for industrial and commercial electrical control applications where a 30.5mm panel cutout is required. Typical installation scenarios include motor starters, conveyor control panels, pump station controls, and machine tool operator stations. The 10250TS54 is part of a modular operator system, allowing it to be combined with contact blocks and legend plates from the same 10250T platform series to complete the full switch assembly.

Key Features

• Standard-type 30.5mm push button operator for industrial control panels
• Part of the modular EATON 10250T operator platform
• Compatible with 10250T series contact blocks and accessories
• Compact and lightweight at 0.1 pounds
• Suitable for low-voltage control circuit applications

Compatibility

Designed as an OEM-style replacement or new-installation operator for industrial control panels requiring a standard 30.5mm push button operator. Specific compatible contact blocks, legend plates, and enclosures were not specified in available product data; consult EATON 10250T series documentation for full accessory compatibility.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC). De-energize and lock out the control panel before removing or installing any operator or contact block. Ensure the panel cutout conforms to the 30.5mm standard before mounting. Torque all electrical terminations to the values specified in the EATON 10250T series installation instructions.

Technical Specifications

• Mounting Diameter: 30.5mm
• Operator Type: Standard Push Button
• Weight: 0.1 pounds
• UPC: 78211336072

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS54
