Eaton 10250TS53 Standard Pushbutton Operator 30.5mm

Product Description

The EATON 10250TS53 is a standard-type pushbutton operator with a 30.5mm mounting diameter, designed for use in industrial control stations and operator interface enclosures. This operator serves as the mechanical actuator component in a pushbutton assembly, providing the contact-activating mechanism used to start, stop, or signal control circuits. Licensed electricians and industrial maintenance technicians install this type of operator as part of panel-mounted or pendant-mounted control stations. Its 30.5mm form factor is a widely recognized standard in industrial control hardware, making it a common replacement or new-installation component in manufacturing, process control, and mechanical equipment applications.

This pushbutton operator is suited for industrial control panel applications where a 30.5mm operator is required. Typical installations include motor control stations, machine tool panels, conveyor control enclosures, and process equipment operator interfaces. It is used in both new panel builds and as a field replacement for worn or damaged operator heads on existing control stations. The standard type designation indicates a conventional non-illuminated operator configuration appropriate for general-duty control circuit applications.

Key Features

• 30.5mm mounting diameter fits standard industrial control station cutouts
• Standard-type operator configuration suitable for general-duty control circuit use
• Lightweight construction at 0.01 pounds for panel-weight-sensitive applications
• Designed as a component-level replacement or new-build actuator for pushbutton assemblies

Compatibility

Designed as an OEM-style operator for 30.5mm industrial pushbutton control stations. Specific compatible contact blocks, legend plates, and enclosures should be verified against EATON 10250T series product documentation.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements. De-energize and lock out the control panel before removing or installing any operator components. Ensure the panel cutout diameter matches the 30.5mm mounting specification before installation. Do not force the operator into an incompatible cutout or housing.

Technical Specifications

• Mounting Diameter: 30.5mm
• Operator Type: Standard
• Weight: 0.01 pounds
• UPC: 78211336071

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS53
