Eaton 10250TS49 Standard Type Push Button Lens

Product Description

The EATON 10250TS49 is a standard-type lens designed for 30.5mm push button operators used in industrial control panel applications. This small-format lens fits over push button actuators to provide visual identification or color coding at the operator interface. It is a direct-fit component intended for use in control stations, operator panels, and machine control enclosures. Electricians and panel builders working on industrial or commercial control systems typically source this part as a replacement or spare during panel assembly or field service. At 0.01 pounds, it is a lightweight plastic component with precise dimensional tolerances suited to flush or standard-depth 30.5mm operator cutouts.

The 10250TS49 lens is used in 30.5mm push button control stations found in industrial facilities, manufacturing environments, and commercial electrical panels. It is suited for applications where a standard-type lens is specified for operator identification on control circuits. This part is appropriate for both new panel builds and replacement service on existing operator stations.

Key Features

• Standard-type lens format for 30.5mm push button operators
• Compact dimensions of 1.7 inches x 1.7 inches x 0.1 inches for precise panel fit
• Lightweight at 0.01 pounds for easy handling during installation
• Designed for use in industrial control panel and machine operator interface applications

Compatibility

Designed as an OEM-style replacement lens for 30.5mm standard-type push button operator assemblies in industrial control panel applications.

Installation Notes

Installation of push button lenses is typically performed by a licensed electrician or qualified panel builder. De-energize the control panel and lock out the circuit before servicing any operator components per NFPA 70E and applicable NEC requirements. Seat the lens firmly onto the push button operator body to ensure proper retention and alignment within the panel cutout.

Technical Specifications

• Type: Standard
• Operator Size: 30.5mm
• Dimensions (L x W x H): 1.7 inches x 1.7 inches x 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211336068

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS49
