Eaton 10250TS47 Selector Switch Lens 30.5mm

Product Description

The EATON 10250TS47 is a standard-type selector switch lens designed for use with 30.5mm push button and selector switch operator assemblies in industrial control applications. This small-profile lens component fits into the operator head and provides a visual indicator window for panel-mounted control stations. Licensed electricians and industrial control technicians install this lens as part of switch assembly builds or as a direct replacement in existing operator hardware. At 0.01 pounds and a compact footprint of 1.7 x 1.7 x 0.1 inches, it is a lightweight, precision-fit component suited for panel shop assembly and field service alike.

This lens is intended for 30.5mm-diameter operator assemblies in industrial control panels, motor control centers, and machine control stations. Typical installations include manufacturing equipment, pump control panels, and process control stations where selector switch operators require a replacement or spare lens. It is installed by electricians and control panel builders working on NEMA-rated enclosures and industrial operator interface stations.

Key Features

• Standard-type lens fits 30.5mm operator assembly footprint
• Compact dimensions: 1.7 x 1.7 x 0.1 inches for precise panel fit
• Lightweight at 0.01 pounds, suitable for high-density panel builds
• Designed for use in industrial selector switch and push button operator heads
• UPC: 78211336066

Compatibility

Designed as an OEM-style lens component for 30.5mm standard-type selector switch and push button operator assemblies in industrial control applications.

Installation Notes

Installation should be performed by a qualified electrician or control panel technician. De-energize the control panel and verify absence of voltage before disassembling any operator hardware. The lens is a snap-fit or press-fit component in most 30.5mm operator heads — do not force or overtighten any retaining hardware. Follow applicable NEC requirements for industrial control panel assembly and maintenance.

Technical Specifications

• Operator Size: 30.5mm
• Dimensions (L x W x H): 1.7 x 1.7 x 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211336066

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS47
