Eaton 10250TS39 Standard Type Pilot Light Lens

Product Description

The EATON 10250TS39 is a standard-type pilot light lens designed for use with 30.5mm indicating lights and pushbutton assemblies in industrial control panel applications. This small-format lens fits into the 10250T series operator interface hardware, providing a visual indicator window for panel-mounted signaling devices. Licensed electricians and industrial control panel builders install this component during new builds and retrofit projects where indicator light clarity and panel aesthetics matter. The lens measures 1.7 inches by 1.7 inches with a 0.1 inch depth and weighs approximately 0.01 pounds.

The 10250TS39 lens is suited for use in industrial control panels, machine operator stations, and process control enclosures where 30.5mm pilot light assemblies are installed. It is a direct-fit component within the EATON 10250T series, commonly found in manufacturing facilities, utilities, and commercial electrical systems requiring durable, panel-mount indicator hardware.

Key Features

• Standard-type lens for 30.5mm pilot light and pushbutton assemblies
• Compact profile at 0.1 inches depth for flush panel integration
• Lightweight at 0.01 pounds, adding minimal load to panel doors
• Part of the 10250T series for broad component interchangeability
• Footprint of 1.7 inches by 1.7 inches for precise panel cutout fit

Compatibility

Designed as an OEM-style replacement lens for EATON 10250T series 30.5mm pilot light and indicating light assemblies used in industrial control panel applications.

Installation Notes

Installation of panel indicator lenses should be performed by a qualified electrician in accordance with NFPA 70 (NEC) and applicable local codes. De-energize the control panel and verify zero voltage at the indicator circuit before servicing any operator interface components. The lens typically snaps or threads into the 10250T series light body without special tooling. Inspect the lens seat for debris or damage before seating to ensure a secure fit.

Technical Specifications

• Series: 10250T Standard Type
• Mounting Diameter: 30.5mm
• Length: 1.7 inches
• Width: 1.7 inches
• Height/Depth: 0.1 inches
• Weight: 0.01 pounds
• UPC: 78211336058

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS39
