Eaton 10250TS32 30.5mm Pilot Light Lens

Product Description

The EATON 10250TS32 is a standard-type pilot light lens designed for use with 30.5mm diameter control station operators. This lens fits into the 10250T series operator hardware and provides a visible indicator window for panel-mounted pilot lights in industrial and commercial control applications. Electricians and control panel technicians install this component as part of pushbutton stations, selector switches, and indicator assemblies on machine control panels and motor control centers. At 0.01 pounds, it is a lightweight replacement lens intended to restore or refresh existing operator assemblies.

This lens is suited for industrial control panels, motor control centers, and operator interface stations where 30.5mm operators are the standard mounting format. It is commonly installed in manufacturing facilities, process control environments, and commercial electrical equipment rooms. The 30.5mm format is widely used in heavy-duty control station applications, making this a frequently specified replacement component for maintenance electricians working on aging or damaged panel assemblies.

Key Features

• Standard-type lens for 30.5mm diameter pilot light operators
• Designed for the EATON 10250T series control station platform
• Lightweight construction at 0.01 pounds for easy handling during panel work
• Direct replacement lens for restoring damaged or discolored indicator windows

Compatibility

Designed as an OEM-style replacement lens for 30.5mm standard-type pilot light operators in the EATON 10250T series control station product line.

Installation Notes

Installation is performed by licensed electricians or qualified control panel technicians. De-energize the control panel and follow lockout/tagout procedures in accordance with NFPA 70E before servicing any operator assembly. The lens typically snaps or threads into the operator body without special tools. Inspect the operator housing and lamp socket for damage before installing the new lens.

Technical Specifications

• Operator Diameter: 30.5mm
• Type: Standard
• Weight: 0.01 pounds
• UPC: 78211336051

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS32
