Eaton 10250TS25 Standard Type Pushbutton Operator

Product Description

The EATON 10250TS25 is a standard-type pushbutton operator designed for use in industrial control and operator interface applications. This 30.5mm operator fits into standard 30.5mm panel cutouts and serves as the actuating component in pushbutton station assemblies. Licensed electricians and industrial maintenance technicians install this type of operator when building or servicing control panels, machine guarding circuits, and motor control stations. The compact form factor and lightweight construction make it straightforward to mount in standard enclosures. It is designed to work within modular pushbutton systems where the operator head, contact block, and legend plate are assembled as separate components.

This operator is suited for light industrial and commercial control panel applications where a 30.5mm pushbutton format is required. Typical installations include motor starters, conveyor control stations, pump control panels, and general machine control enclosures. It is intended for use by qualified electricians working on low-voltage control circuits in compliance with applicable NEC requirements.

Key Features

• Standard 30.5mm operator format for compatibility with standard panel cutouts
• Lightweight construction at 0.010 pounds
• Compact dimensions: 1.7 inches x 1.7 inches x 0.1 inches
• Modular design intended for assembly with compatible contact blocks and legend plates
• Part of the EATON 10250T series operator interface product line

Compatibility

Designed as an OEM-style replacement or new-installation operator for 30.5mm pushbutton station assemblies. No specific compatible model numbers were provided in the product data.

Installation Notes

Installation should be performed by a qualified electrician with the control panel de-energized and locked out per NFPA 70E lockout/tagout procedures before any work begins. The operator mounts into a standard 30.5mm panel cutout and is typically secured with a jam nut or retaining ring. Contact blocks and legend plates are assembled separately according to the manufacturer assembly instructions. Verify that all modular components are fully seated and secured before restoring power.

Technical Specifications

• Operator Size: 30.5mm
• Dimensions (L x W x H): 1.7 inches x 1.7 inches x 0.1 inches
• Weight: 0.010 pounds
• UPC: 78211336044

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS25
