Eaton 10250TS13 Standard Type 30.5mm Pilot Light Lens

Product Description

The EATON 10250TS13 is a standard-type replacement lens designed for 30.5mm pilot light and pushbutton operator assemblies. It fits into the 10250T series operator platform and provides a clear or colored light-diffusing face for panel-mounted indicator lights used in industrial control panels. Electricians and panel builders install this lens when replacing damaged or discolored indicator covers during maintenance. At 0.010 pounds and measuring approximately 1.7 inches by 1.7 inches by 0.1 inches, it is a lightweight, low-profile component suited for tight enclosure layouts.

This lens is intended for use in industrial control panels, machine operator stations, and motor control centers where 30.5mm operator devices are installed. It is a direct service-replacement part for the 10250T series pilot light assemblies commonly found in manufacturing, process control, and utility environments. Installation is performed by qualified electricians during scheduled panel maintenance or emergency component replacement.

Key Features

• Standard-type lens format for 30.5mm pilot light and indicator assemblies
• Low-profile design at 0.1 inches thick for compact panel installations
• Lightweight construction at 0.010 pounds minimizes operator assembly load
• Fits the EATON 10250T series operator device platform
• Square footprint of 1.7 inches by 1.7 inches for consistent panel cutout alignment

Compatibility

Designed as a standard-type replacement lens for EATON 10250T series 30.5mm pilot light and pushbutton operator assemblies used in industrial control panel applications.

Installation Notes

Installation is performed by a licensed electrician or qualified control panel technician. De-energize and lock out the control panel per NFPA 70E procedures before servicing any operator device. The lens typically snaps or threads into the operator body without special tooling. Verify the replacement lens type and color match the original assembly before returning the panel to service.

Technical Specifications

• Operator Size: 30.5mm
• Length: 1.7 inches
• Width: 1.7 inches
• Height (Depth): 0.1 inches
• Weight: 0.010 pounds
• UPC: 78211336033

Standard Information

• Brand: EATON
• Manufacturer Part Number: 10250TS13
